The Model 7540 from GP:50 is a highly rugged differential pressure transducer, designed to address the tough environmental challenges of subsea and other marine service environments. It is manufactured and tested to stringent MIL and MIL-spec standards for high-reliability within extreme environments.
Model 7450 is a high accuracy aerospace grade, high line – low range differential pressure transducer available with static line pressure to 5,000 PSI. Differential ranges as low as 0-2.5” WCD and a 500 PSI proof pressure are standard on all ranges. A custom subsea rated design allows operation to 23,000 FT SW.
The Model 313F Flush Submersible Level Transmitter utilizes a flush 1.12” diameter ceramic sensor that inhibits grease and biosolid buildup typically found in water treatment level applications. This flush ceramic design saves cost by eliminating sensor clean-out found with many other non flush designs. The corrosion-resistant 316L stainless steel construction, and an integrated hydrophobic breather vent help provide years of maintenance-free service.
• Large, flush ceramic diaphragm • Corrosion resistant, leak-proof construction • Designed to 500 PSI external pressure • Flush design saves cost & down time by eliminating sensor clean up
The Model 313L from GP:50 is a line of highly accurate and reliable submersible level transmitters. The corrosion-resistant 316L stainless steel construction, and an integrated hydrophobic breather vent help provide years of maintenance-free service.
Model 313L-NI utilizes an all-titanium design to provide long term stability and continued performance under the harshest conditions, including corrosive and hazardous chemical applications. The slim design and high media resistance perform exceptionally well in down-hole applications that often have tight space constraints and caustic environmental conditions.
Model 313S Slim Submersible Level Transmitter from GP:50 has all the same features as our popular 313L but with a slim 0.685” (17.4 mm) diameter housing for those applications that have limited installation space. All GP:50 submersible level transmitters are built with a rugged leak-proof stainless steel construction, lightning surge protection and an integrated hydrophobic filter to provide accurate level measurement with years of corrosion free service for all types of level applications.
Model 313G utilizes a flush ceramic sensor to reduce grease and bio-solid buildup and minimize cleanup. The chemical resistant PVC provides stability and continued performance under the harsh conditions associated with waste water and other aggressive media applications.
The Model 1002/1003-IA from GP:50 is an industrial grade OEM pressure transducer featuring a G ½” flush corrosion-resistant pressure port. This flush port is specifically designed for high viscous liquids that can plug a standard recessed process port. Units are available with choice of 4-20 mA, 0 to 5 Vdc or 0 to 10 Vdc output, as well as various electrical connections.
The Model 1102/1103 from GP:50 is a family of submersible level transmitters, designed to provide high-accuracy measurements at a competitive price point. They are offered with an all 316L stainless steel construction for extended corrosion-free service life. An optional sludge screen is available for viscous media or wastewater applications.
The Model 913 from GP:50 is a high-accuracy submersible level transmitter. It features an asynchronous serial communication output (SDI-12-v 1.3), typically used to monitor environmental data. This also allows for communication with compatible data loggers or data acquisition systems. The incorporation of a hydrophobic breather vent ensures extended trouble-free service within demanding applications. These features, combined with the low power requirements of the Model 913, make it particularly ideal for remote well monitoring applications.
The Model 7500-9000 Series from GP:50 is a high-accuracy pressure and temperature transmitter, offering more than 15 years of field proven pedigree within subsea wellhead applications. The Series features a robust design with all stainless steel housings and wetted parts, full seawater submersibility to 30K ft (9,144 M) and an API flanged process connection. An optional redundant sensor provides backup pressure and temperature outputs, in the case of prime element failures or cabling issues. Optional HART communication protocols are available for remote measurements.
The rugged Model 7500 subsea pressure level transducer from GP:50 is designed to provide accurate measurements to 30,000 FT seawater. Its highly corrosion-resistant design meets the tough environmental challenges of offshore oil and gas, naval and ROV applications. Manufactured and tested to stringent MIL-spec standards the Model 7500 provides years of highly accurate, reliable use.
The 7500-M254 from GP:50 is a subsea pressure transducer, designed for use within remote or unmanned vehicles. Its open reference provides for sea depth pressure. When used in a non-conductive fluid bladder, the transducer also provides a gauge process pressure. In addition to ROV applications, the compact size and sea rated construction of the 7500-M254 make it ideal for the effective monitoring of subsea oilfield wellhead control systems.
The Model 7850 from GP:50 is a rugged, sub-sea temperature transducer, tested to 30,000 FT sea water. The highly corrosion resistant design meets the tough environmental challenges of offshore oil and gas, Naval and ROV applications.
